OKM Rover C4 (2017-2021)
June 07, 2021
This product has been updated. View the current product version: OKM Rover C4
- Bestseller: 3D ground scanner and metal detector
- Depth: Customers found objects to 25 m (82 ft) deep
- Use cases: treasure hunting, natural gold prospection
- Operating modes: Ground Scan, Pinpointer, Magnetometer, Mineral Scan
- Detectable objects: natural gold minerals, treasure chests, jewelry, militaria
Ground Scanner Rover C4 Features:
Use of Metal Detector OKM Rover C4:
Special Features of Rover C4
- Supported operating modes: Ground Scan, Pinpointer, Mineral Scan, Magnetometer
- Graphical user interface in many different languages
- Operational touchscreen with alternative hardware buttons
- Multilevel LED lighting for usage of the detector in darkness
- Wireless data transfer
- 4 separate memory areas to store measuring data
- Standard Probe and Super Sensor with innovative LED Orbit
| 1x | Control unit |
| 1x | Standard Probe with LED Orbit |
| 1x | Super Sensor with LED Orbit |
| 1x | Windows Tablet PC |
| 1x | Software Visualizer 3D Studio Standard Edition |
| 1x | Bluetooth headphones |
| 1x | Power Pack with charger and travel adapter |
| 1x | USB Bluetooth dongle |
| 1x | Waterproof and shock resistant Pelican case |
| 1x | Carrying tube |
| 1x | Quick Start Guide |
Control unit
- Dimensions (H x W x D): 390 x 300 x 140 mm
- Weight: about 1.5 kg
- Input voltage (max.): 11 – 13 V DC / 6 W
- Processor / Main CPU: Cortex M3, 32 MHz
- Processor / Slave CPU: Cortex M0, 24 MHz
- Display: 3.5” Resistive touch, 480 x 320 Pixel
- Display CPU: Cortex M3, 32 MHz, 128 KB RAM
- Data memory: 4 GB
- Sample rate: 1024 values / second
- Measurement resolution: 16 bit
- Operating temperature: –10°C – 60°C
- Storage temperature: –20°C – 70°C
- Audio: Internal speaker / Bluetooth
- Waterproof: No
- Air humidity: 5% – 75%
Standard Probe
- Weight: 0.4 kg
- Length: 445 mm
- Diameter tube / LED Orbit: 35 mm / 65 mm
- Technology: SCMI-15-D
Super Sensor
- Weight: 0.9 kg
- Length: 960 mm
- Diameter tube / LED Orbit: 50 mm / 65 mm
- Technology: SCMI-15-D
Data transmission
- Technology: Bluetooth
- Frequency: 2.4 – 2.4835 GHz
- Maximum Transfer Rate: 1 Mbps
- Receiving Sensitivity: –85 dBm
- Maximum Range: approx. 10 m
Computer minimum requirements
- CD-ROM drive: minimum 4x
- Interface (Data transmission): USB
- Free disk space: minimum 50 MB
- Working memory (RAM): minimum 256 MB
- Graphic card: minimum 128 MB, OpenGL-compatible
- Processor: minimum 1.2 GHz
- Operating system: Windows Vista, Windows 7, Windows 8, Windows 10
This product has been updated. View the current product version: OKM Rover C4
Rover C4 Quick Tutorial Transfer Scan Files
After performing your scans, transfer them to the Windows notebook via Bluetooth for further analysis.
Rover C4 Features
In this video we want you to catch a glimpse of our redesigned Rover C4.
Behind the Scenes: Making of OKM Tutorials
The video shoot for the current Rover C4 tutorials took place in a former gravel pit: Perfect to test the ...
